Ni-MH Button Rechargeable Cells


Details
Type Rated
Capacity
( mAh )		 Nominal
Voltage
( V )		 Diameter
( mm )		 Height
( mm )		 Charging Discharging Data
Sheet		 Application...
20H 20  1.2 11.6 3.1 2mA x 16h 4mA / 1.0V
28HB 25 1.2 7.9 5.4 2mA x 16h 5mA / 1.0V
 30HB  35  1.2 9.5 5.4  4mA x 16h  7mA / 1.0V
 40H   40   1.2  11.6  5.4  4mA x 16h  8mA / 1.0V
  40H2  40  1.2  11.6  5.4  4mA x 16h   8mA / 1.0V
 80H 80  1.2  15.2  6.1  8mA x 16h   16mA / 1.0V
 80H2 80  1.2  15.4  6.1  8mA x 16h   16mA / 1.0V
 80H2T   80  1.2   15.4   6.1  8mA x 16h
High Temperature		  16mA / 1.0V
110H2 110 1.2 15.4  7.8 11mA x 16h 22mA / 1.0V
160H  160  1.2 23.5 x 15.1 x 5.7   16mA x 16h    32mA / 1.0V
230H  230  1.2 25.2  6.4  23mA x 16h    46mA / 1.0V
330H  330  1.2 25.2   8.8  33mA x 16h   66mA / 1.0V
330mA / 0.9V
